DN-8K16P16R 16-channel DI, 16-channel Relay (Form A, 3A) Output Board


Price:
Sale price£168.00

Description

The DN-8K16P16R is a16-channel DI, 16-channel relay (Form A, 3A) Terminal Board (Pitch= 3.81 mm) with DIN-rail Mounting (RoHS)
Includes: CA-3705A (DB37 Male to Female Cable, 90º, 0.5 M)

Model: I-8042W and I-87042W with DN-8K16P16R

Features

  • 37-pin D-sub connector to quickly link to a I-8042W or I-87042W
  • 16 Form A Signal Relay
  • 16 LEDs to display the state of individual relays
  • Screw terminals for field wiring
  • Power Input: +12 ~ 30 VDC
  • DIN-Rail mounting for industrial usage

Specifications

Digital Input
Channels 16
Type Pin-to-pin terminals
Relay Output
Channels 16
Contact Rating Form A:
3 A @ 250 VAC
Operate Time Form A: 10 ms
Release Time Form A: 5 ms
Mechanical Endurance SPST:10,000,000 ops.
Power
Input Range +12 ~ 30 VDC
Consumption 3.75 W Max.
Mechanical
Dimensions (mm) 118 x 174 (W x L)
Installation DIN-Rail mounting
Environment
Operating Temperature -25 ~ 75°C
Storage Temperature -30 ~ +85℃
Humidity 10% ~ 90% RH, Non-condensing
